Apple teardowns

Read Cult of Mac’s latest posts on Apple teardowns:

Crazy-thin iPad Pro models hold up under early bend tests

By

M4 iPad Pro bend tests
It turns out your super-thin M4 iPad Pro can stand up to some serious bending.
Photo: JerryRigEverything

Three new videos test just how “bend-but-don’t-break” Apple’s new super-thin M4 iPad Pro is, and the answer is “very.” Reviewers came away impressed by how well even the ultra-thin 13-inch M4 iPad Pro performed. And the 11-inch model did well, too.

JerryRigEverything performed bend tests as part of a teardown of the 13-inch M4 iPad Pro. AppleTrack stuck with comparing bends of 11- and 13-inch 2024 iPad Pro models against the 2022 versions. And MobileReviewsEh showed new models held up under massive pressure about as well as older models despite being about 20% thinner.

These CT scans show Vision Pro’s glorious guts like nothing else

By

Lumafield CT scan Vision Pro
An internals-only scan gives you a sense of how much Apple artfully packs into Vision Pro.
Photo: Lumafield

Want to see exactly what advanced engineering lies inside a Vision Pro AR/VR headset compared to Meta Vision Quest headsets? Lumafield dropped a fascinating video and a series of CT-scan images Tuesday to show you.

Lumafield pointed out it’s aim is not to present a head-to-head comparison or product review, but to reveal the companies’ “divergent design philosophies” through the headsets’ hardware engineering.

Vision Pro teardown finds pixels smaller than a red blood cell

By

Apple Vision Pro teardown: Display screen
The centerpiece of Vision Pro are its amazing display screens.
Photo: iFixit

iFixit’s Apple Vision Pro teardown continues, now with a focus on the headset’s incredibly high-resolution displays. As the experts point out, “You can fit ~54 Vision Pro pixels into a single iPhone pixel.”

However, the screen looks to the viewer like it’s a lower resolution than an iPhone.

Vision Pro teardown gives a look inside Apple’s $3,499 headset

By

Vision Pro teardown
Vision Pro gets the teardown treatment.
Photo: iFixit

An Apple Vision Pro teardown shows the complicated combination of screens, cameras and other high-end components inside the $3,499 headset. The hardware required just to produce the creepy (and much-maligned) EyeSight feature is somewhat staggering.

Like other Apple products, getting inside the Vision Pro is not easy. You will need a heat gun, a prying tool, multiple screwdrivers and lots of patience.

New teardown video zooms in 7,000x on iPhone 15 guts

By

This borrowed microscope lets the video zoom in thousands of times on iPhone 15 components.
This borrowed microscope lets the video zoom in thousands of times on iPhone 15 components.
Photo: iFixit

iFixit brought in a new toy for its iPhone 15 teardown video Friday — an Olympus DSX1000 digital microscope. That enabled magnification of up to 7,000x on the tiny bits inside Apple’s newest base handset.

Watch the video below and see some shots from it above and below.

iFixit shows how to add a hole to AirTag

By

Drill an AirTag hole at your own risk.
If you’re willing to risk ruining an AirTag, you can drill a hole in it.
Photo: iFixit

There’s no direct way to attach Apple’s just-released AirTag to a set of keys because the item tracker doesn’t include a hole. But iFixit x-rayed the device and found three places a brave user could drill a hole.

Nixed bilateral charging could have been iPhone 11 Pro exclusive

By

iPhone 11 teardown disassembled
Taking an iPhone 11 to pieces finds no sign of one rumored feature, but hints Apple Tags could still be on the way.
Photo: iFixit

A teardown of the iPhone 11 finds Apple’s less-expensive handset lacks any sign of inverse wireless charging. iFixit did discover hardware possibly related to this rumored feature in the iPhone 11 Pro series, however.

An X-ray of the iPhone 11 does turn up evidence of ultra-wideband support, however. That will prove important if Apple launches the item-tracking tags that also showed up in many rumors.

First iPhone 11 Pro Max teardown shows off gigantic new battery

By

iPhone Pro Max battery life gets an extra 5 hours
A larger battery will contribute to a longer time between charges for the iPhone 11 Pro Max.
Screenshot: Apple

A teardown video divulges one of the specs Apple refuses to reveal about the iPhone 11 Pro Max. The new phone includes a 3,969 mAh battery, significantly larger than the one inside the XS Max.

See other internal details of Apple’s new flagship device by watching the teardown video below.

iPhone XS reveals its secrets in first teardown video

By

The first iPhone XS teardown video shows the unusual L-shaped battery.
The first iPhone XS teardown video shows the unusual L-shaped battery.
Photo: FixjeiPhone

The iPhone XS debuts tomorrow, but a video showing this device being disassembled is already available. This not only gives the first look at the internal components but reveals some of the details about this smartphone.

Perhaps the most unusual feature of Apple’s new high-end model is the L-shaped battery.

Apple’s new 4K iMac takes steps toward greater repairability

By

OpqQbulpghQImyZZ.huge
New 21.5-inch iMac features removable RAM and CPU.
Photo: iFixit

Apple’s new 4K 21.5-inch iMac is slightly more repairable than its predecessor, a new teardown by iFixit reveals. But there’s one big surprise buried in the computer’s guts: Both the CPU and the RAM can be swapped out when it’s time to upgrade.

While it’s still not an easily repairable computer, that’s still a change of direction for a company whose products regularly get dinged for lack of upgradeability.

MacBook Pro teardown reveals mystifying speaker grilles

By

clA1FMegMLVjVjCb.huge
Ooh, new speakers! Well, not so fast...
Photo: iFixit

Apple’s new MacBook Pro with Touch Bar have arrived, and our friends at iFixit have already dutifully taken one apart to reveal what’s lurking under the surface.

The most interesting revelation? The laptop’s new speaker grilles don’t house new speakers, but may instead exist purely for design purposes.

You think Apple’s Smart Battery Case is ugly? Wait ’til you see its insides

By

It's what's inside that counts.
It's what's inside that counts.
Photo: iFixit

For the Apple fans disappointed in the Quasimodo look of the new Smart Battery Case, there is probably great satisfaction in seeing it all busted up. Yes, the staff at iFixit wasted no time prying one open to behold the guts of the beast.

iFixit did not defend the case from the “ugly” tag so many people gave it in its’ first 24 hours of public life. The technicians were impressed with the ducting on the case, which turned a downward-facing speaker into one that faces forward. The microphone also faces forward and iFixit wonders if this a preview on future designs.

iPad Mini 4 teardown reveals a miniaturized Air 2

By

iPad Mini 4 teardown by iFixit
The EU wants gadgets that are easier to fix and upgrade.
Photo: iFixit

We’ve gotten our first look at the guts of the latest Apple hardware thanks to an iPad Mini 4 teardown that’s appeared online, and the new tablet from the Cupertino company is looking really familiar. But we don’t mean that in a bad way.

Repair-advise site iFixit has sacrificed one of the devices in the name of science and education, and its findings reveal that at its heart, the iPad Mini 4 is a smaller version of the upper-tier iPad Air 2. Here’s what the carnage revealed.

The new Retina MacBook could be Apple’s least-repairable notebook yet

By

The new MacBook in pieces. Photo: iFixit
The new MacBook in pieces. Photo: iFixit

Apple’s new MacBook may be one “for the future” but it’s already had a teardown from our friends over at iFixit, filling you in on all the ways the next-gen notebook differs from its predecessor.

That includes Apple’s butterfly mechanism keys, its Force Touch trackpad, form-fitting layered battery, and, of course, the thinnest, most energy-efficient Retina display ever seen on a Mac.

It’s not just ports the new notebook is missing, however. It’s also one of Apple’s least-repairable notebooks to date!
